Cisco 8010 Series Large Density Fixed Routers Data Sheet Cisco 8010 routers Fixed platform with advanced timing, security, and QoS.Bandwidth: Up to 1.6 Tbps Height: 1 RU

Powered by the Cisco Silicon One^™ A100 ASIC, the Cisco^® 8010 Series Large Density Fixed Routers offer Class C timing support and end-to-end encryption, enabling seamless network growth and scalability. Built on the robust Cisco IOS^® XR operating system, these routers are designed for use in dense metro access and preaggregation deployments, delivering both Capital Expenditure (CapEx) savings and enhanced operational simplicity.

Product overview

Building on the success of our Cisco 8000 Series Routers, which use the Cisco Silicon One^™ ASIC, we are thrilled to introduce the Cisco 8010 Series, powered by the new A100 ASIC. This unified silicon architecture eliminates boundaries across a significant portion of the networking market, providing scalability from web-scale to service provider deployments. The Cisco 8010 Series offers versatile Ethernet interface options, ranging from 1G and 25G to 100G and 400G. These industrial-temperature devices support Class C timing and feature encryption capabilities, including MACsec at line rate on all ports and IPsec for data security.

Product Details

Key product highlights

● 1 Rack-Unit (1RU) fixed form factor

● Versatile Ethernet interface options: 1/10/25G and 40/100G

● G.8273.2 Class C Timing compliant

● Modular GNSS with Primary Reference Time Clock Class B (PRTC-B) for better performance

● Suitable for indoor or outdoor (sealed IP65/IP66 cabinet with heat exchanger conforming to GR487 specs with sufficient cooling) cabinets

● MACsec and IPsec support for secure data communication¹

● Fully compliant with the MEF 3.0 standard for wireline networks²

● Rich packet Ethernet Operations, Administration, and Management (OAM) capabilities, including Y.1564 SADT

● Power-optimized router with advanced algorithms for reduced Operating Expenses (OpEx)

● Based on Cisco IOS XR Flexible Consumption Model (FCM) 2.0
